Type: Full Range
Nominal Diameter: 380 mm (15.0 in)
Impedance: 8 ohms
RMS Power Handling: 650W
Sensitivity (1W/1m): 100 dB
Continuous Power Handling: 1300W
Frequency Range: 40-200 Hz
Voice Diameter: 89 mm (3.5 in)
Winding Material: Copper
Former Material: Glass Fiber
Winding Depth: 16.0 mm (0.62 in)
Magnetic Gap Depth: 10.5 mm (0.4 in)
Flux Density: 1.5T
Weight: 5.16 kg
Type: Subwoofer
Nominal Impedance: 8 ohms
Minimum Impedance: 6.2 ohms
RMS Power Handling: 1800W
Nominal Power Handling: 3600W
Sensitivity (1W/1m): 96 dB
Frequency Range: 30 - 100 Hz
Voice Coil Diameter: 115 mm (4.5 in)
Winding Material: Copper (2 layers)
Former Material: Glass Fiber
Magnet Material: Feride Inside Slug
Winding Depth: 30 mm (1.18 in)
Magnetic Gap Depth: 12 mm (0.5 in)
Flux Density: 1.2
Weight: 15.5 kg
Type: Subwoofer
Nominal Impedance: 8 ohms
Minimum Impedance: 6.2 ohms
RMS Power Handling: 2000W
Nominal Power Handling: 4000W
Sensitivity (1W/1m): 96 dB
Frequency Range: 30-100 Hz
Voice Coil Diameter: 127 mm (5 in)
Winding Material: Copper (2 layers)
Former Material: Glass Fiber
Magnet Material: Feride Inside Slug
Winding Depth: 30 mm (1.18 in)
Magnetic Gap Depth: 12 mm (0.5 in)
Flux Density: 1.21
Weight: 26 kg
Type: Subwoofer
Nominal Impedance: 8 ohms
Minimum Impedance: 6.2 ohms
RMS Power Handling: 2000W
Nominal Power Handling: 4000W
Sensitivity (1W/1m): 96 dB
Frequency Range: 30-100 Hz
Voice Coil Diameter: 127 mm (5 in)
Winding Material: Copper (2 layers)
Former Material: Glass Fiber
Magnet Material: Feride Inside Slug
Winding Depth: 30 mm (1.18 in)
Magnetic Gap Depth: 12 mm (0.5 in)
Flux Density: 1.21
Weight: 26 kg
Type: Subwoofer
Nominal Impedance: 8 ohms
Minimum Impedance: 6.2 ohms
RMS Power Handling: 2000W
Nominal Power Handling: 4000W
Sensitivity (1W/1m): 96 dB
Frequency Range: 30-100 Hz
Voice Coil Diameter: 127 mm (5 in)
Winding Material: Copper (2 layers)
Former Material: Glass Fiber
Magnet Material: Feride Inside Slug
Winding Depth: 30 mm (1.18 in)
Magnetic Gap Depth: 12 mm (0.5 in)
Flux Density: 1.21
Weight: 26 kg
Type: Subwoofer
Nominal Impedance: 8 ohms
Minimum Impedance: 6.2 ohms
RMS Power Handling: 2000W
Nominal Power Handling: 4000W
Sensitivity (1W/1m): 96 dB
Frequency Range: 30-100 Hz
Voice Coil Diameter: 127 mm (5 in)
Winding Material: Copper (2 layers)
Former Material: Glass Fiber
Magnet Material: Feride Inside Slug
Winding Depth: 30 mm (1.18 in)
Magnetic Gap Depth: 12 mm (0.5 in)
Flux Density: 1.21
Weight: 26 kg
Type: Subwoofer
Nominal Impedance: 8 ohms
Minimum Impedance: 6.2 ohms
RMS Power Handling: 2000W
Nominal Power Handling: 4000W
Sensitivity (1W/1m): 96 dB
Frequency Range: 30-100 Hz
Voice Coil Diameter: 127 mm (5 in)
Winding Material: Copper (2 layers)
Former Material: Glass Fiber
Magnet Material: Feride Inside Slug
Winding Depth: 30 mm (1.18 in)
Magnetic Gap Depth: 12 mm (0.5 in)
Flux Density: 1.21
Weight: 26 kg
